Descrizione
| Telaio | Reacto CF3 IV material: carbon 700x30C max. wheelsize 100×12/ 142x12mm axle standard BB86,5 bottom bracket standard |
|---|---|
| Serie Sterzo | FSA ACR |
| Forcella | Reacto CF3 IV DISC material: carbon 700x30C max. wheelsize |
| Battute Mozzi | Front: 100mm; Rear: 142mm |
| Mozzi | VP CLK170F / VP 270SB |
| Mozzo Anteriore | 100x12mm width front hub 28 spoke holes, Centerlock |
| Mozzo Posteriore | 12-142mm width rear hub 28 spoke holes Centerlock |
| Cerchi | Merida Expert CW 19mm inner width 30mm height material: aluminium Tubeless ready (tubeless tape and valves not included) |
| Raggi | Double Butted Black stainless |
| Tipo Gonfiaggio | Tubeless |
| Pneumatici | Continental Ultra Sport III 700x25C fold |
| Freni | Shimano Ultegra Hydraulic disc rotors Shimano RT64 160mm |
| Comandi | Shimano Ultegra disc |
| Deragliatore Anteriore | Shimano Ultegra |
| Deragliatore Posteriore | Shimano Ultegra |
| Guarnitura | Shimano RS510 52-36 teeth 165 mm-XXS/XS, 170 mm-S, 172.5 mm-M, 175 mm-L/XL |
| Movimento Centrale | SM-BB71-41B, Pressfit 86.5 |
| Pacco Pignoni | Shimano CS-R7000 11-30 teeth 11 speed |
| Catena | KMC X11 |
| Pedali | Not Included |
| Sella | Merida Expert CC V-mount incl. MERIDA minitool |
| Reggisella | Merida Team CW Aero shape 15mm setback Carbon |
| Attacco Manubrio | FSA SMR ACR material: aluminium -6° stem angle 90 mm-XXS/XS, 100 mm-S, 110 mm-M, 120 mm-L/XL |
| Manubrio | Merida Expert CW material: aluminium 380mm (XXS) 400mm (XS-S) 420mm (M) 440 (L-XL) |
| Manopole | One-Touch |
